Hammersmith Technical Institute Section A - Gas and Water Services
Date
7 Sep 1905
Creator(s)
Code
UAL/4/1/1/2/1
Catalogue link
A plan of the gas and water utilities on the ground floor and mezzanine level between the ground and first floor.
