L.C.C. Hammersmith Trade School for Girls: Details of Hatchway: Screen in First Floor Corridor
Date
11 Mar 1913
Creator(s)
Code
UAL/4/1/1/5/1
Catalogue link
A plan showing details and sections of the hatchway, the screen in the first floor corridor, the coal bin and the cove cornice.
